Saonon Containerized Genset Powered by Yuchai
Saonon Containerized Genset Powered by Yuchai
Saonon Containerized Genset Powered by Yuchai

Powered by Yuchai

Containerized Genset
Powered by renowned Yuchai engine; Optional choose alternator, such as Mister, Stamford, LeroySomer, etc; Equipped with world advanced control panel
  • Photo
  • 360 Degree View
  • Saonon Containerized Genset Powered by Yuchai
  • Saonon Containerized Genset Powered by Yuchai
  • Saonon Containerized Genset Powered by Yuchai
  • Features
  • 50HZ

Power Range

Above 625kVA(50Hz、60Hz)



Product Description

● 20 and 40 feetcontainer can be adopted based on power range;

● Side doors aremounted on both sides of container, convenient for daily check and maintenance.

● Cat ladder canbe equipped above 500kW containerized generating sets, making it easier forlifting and point inspection.

● External oilfilter design can ensure the fuel safety when generating sets outside.

● Cabinet and baseframe are made of high quality slabs and coated with excellent coatingmaterial, with three layers of bottom-medium-top spraying process and high anticorrosion and antirust capacity.



Noise Reduction Development

● The overheadmuffler and piping system has enlarged the lading space and can be greatlyconvenient for machine repair;

● The inner ofcontainerized canopy has been treated by noise reduction, the walls and the topare both treated by sound-absorbing and heat insulation.



Safety Design

● Thecontainerized genset is designed for rainproof and sand proof that can be usedin windy desert area. The anti-rat net has been installed outside the doors andwindows to prevent small animals entering causing damage;


Build-InIndependent Tank

● Build-in largescale independent tank can satisfy the normal operation of genset.


Convenient Transportation

● Therestructuring standard of containerized genset meets the requirements ofnational standard GB/T1413 and GB/T1992 as well as the demands of seatransportation and land transportation.


Applicationscope

● It is applied in various construction sites, such ashuge buildings, airports, harbors, offshore operation platforms and fieldprojects, etc.
